USB2.0 Communication YIXIST YPM-8201-02 Optical Power Meter 2023 Model 4-Inch LCD

Name: USB20 Communication YIXIST YPM820102 Optical Power Meter 2023 Model 4Inch LCD
Brand: YIXIST
Price: 442.00 USD

Wholesale USB2.0 Communication YIXIST YPM-8201-02 Optical Power Meter 2023 Model 4-Inch LCD from china suppliers

Warranty : 1 year

Customized support : OEM, ODM

Place of Origin : Zhejiang, China

Brand Name : YIXIST

Model Number : YPM-8201-02

Size : 160mm*120mm*40mm

Weight : 0.65Kg, 0.65Kg

Model : YPM-8201-02

Dimension : 160mm*120mm*40mm

Display frequency : 10Hz

Number of data storage : 10000 groups

Communication interface : USB2.0

LCD type : 70mmx70mm HD screen

Applicable battery type : Built-in 8000mAh polymer rechargeable battery

Power adapter : Input:100-240VAC, Output:6VDC1A

Price : $442.00/pieces 1-9 pieces

MOQ : 1 unit

Contact Now

USB2.0 Communication YIXIST YPM-8201-02 Optical Power Meter 2023 Model 4-Inch LCD

PRODUCT OVERVIEW

The YPM-8201-02 is a handheld optical power meter with excellent performance, providing an ideal choice for optical power measurement: high accuracy, easy operation and reliability. The meter has a moderate form factor, a 4-inch LCD display, three power supply options: adapter, USB and rechargeable battery, digital high speed HD display, digital filtering and real-time display of power value, minimum, maximum and average values. The meter communicates with the photoelectric detector and integrating sphere detector through digital transmission to ensure the accuracy of the data. And it can be connected to computer through USB interface and display test data through YSW-5002 optical power measurement software, which supports up to four channels of data acquisition at the same time, displaying maximum and minimum power values, average value, standard deviation and PTP , and can do storage or import analysis of data, which is convenient for users.

Cross-border design: suitable for portable and desktop use

The handheld design can store over 10,000 sets of data in a single unit and allows three power supply modes: built-in battery, USB and external adapter, making it ideal for engineers to carry around.

Compatible with digital and analog type detectors

To take into account the characteristics of both strong and weak signal probes, the meter head is compatible with both digital communication and analog communication type probes.

Professional monitoring and data analysis

To take into account the characteristics of both strong and weak signal probes, the meter head is compatible with both digital communication and analog communication type probes.

Secondary development

It is possible to do secondary development or integration via USB or RS232 interface, or to monitor the power value through the SMA905 interface with 0-2.5V output voltage.

Application

Laser power measurement and monitoring. Measurement of optical loss of optical fiber, optical cable and various passive optical devices. Line construction and maintenance of communication projects (such as local area networks, cable and long distance lines). Research and testing of fiber optic cables, optical communication equipment, active and passive optical devices. Measurement of the power density of ultraviolet radiation energy in the sun.

PRODUCT SPECIFICATIONS

Name	YPM-8201-02
Optional detector	YPM-8202 series photoelectric detector YPM-8203 series thermopile detector YPM-8205 series integrating sphere detector
Display frequency	10Hz
Number of data storage	10000 groups
Communication interface	USB2.0
LCD type	70mmx70mm HD screen
Applicable battery type	Built-in 8000mAh polymer rechargeable battery
Power adapter	Input:100-240VAC, Output:6VDC1A
Weight	0.65Kg
Size	160mmx120mmx40mm

RELATED ACCESSORIES

Photodetector

Integrating Sphere Power Detector

Thermopile Power Detector

COMPANY PROFILE

YIXI Smart Technology (YIXIST) Co., Ltd.

YIXIST is an innovative technology enterprise based on advanced optical measurement technology, which is determined to become the best supplier and advanced technology provider in the intelligent equipment manufacturing industry to create the greatest value for customers globally.

Currently we're working with hunderds of well known universities and research institutions in China and are actively involved in offline events as Education Seminars and Exhibitions.
